The Thermaster GN3100TNC 2x3 Solid Door Pass-Through Refrigerated Island Counter is an elite, double-sided commercial prep bench refrigerator engineered specifically for high-volume Australian commercial kitchens, central prep islands, catering operations, and fast-paced plating lines. Featuring solid doors on both the front and rear faces, this innovative 1795mm wide pass-through island counter allows kitchen and plating teams positioned on opposite sides of the bench to access the same chilled stock simultaneously—eliminating unnecessary steps and accelerating kitchen service workflows.
Constructed entirely from premium AISI 304 food-grade stainless steel inside and out, the GN3100TNC offers an expanded 324-litre gross storage volume sized specifically to fit standard GN 1/1 gastronorm pans. Engineered to withstand tough Australian kitchen environments (rated for high ambient conditions up to +40°C / 40% RH), it maintains a versatile holding temperature range of -2°C to +8°C. Driven by a ventilated air circulation system, it includes 60mm high-density HC-free insulation, tool-free magnetic door gaskets, heated door frames to eliminate condensation, automatic defrosting, and auto-evaporation drainage. Operating on a standard single-phase 10 Amp power supply (300W), it is backed by up to 4 years of total warranty coverage upon online product registration.
Why Choose the Thermaster GN3100TNC Pass-Through Island Counter?
Choosing the Thermaster GN3100TNC Pass-Through Refrigerated Island Counter equips commercial kitchens with a space-optimized, highly accessible, and durable prep workstation designed to maximize staff efficiency across busy service shifts.
Key reasons commercial kitchen operators specify the Thermaster GN3100TNC include:
-
Dual-Sided Pass-Through Efficiency: Solid doors on both sides enable prep cooks and pass staff to reach inside the same cabinet simultaneously without walking around the island bench, cutting foot traffic and speeding up plating times.
-
Full AISI 304 Stainless Steel Construction: Premium commercial AISI 304 grade stainless steel interior and exterior with coved internal corners delivers maximum structural durability, stain resistance, and fast end-of-shift sanitisation.
-
GN 1/1 Gastronorm Compatibility: Internal cabinet configuration accommodates standard GN 1/1 food pans and shelving grids, allowing seamless transfer of prepped ingredients directly from primary storage into the island bench.
-
High Ambient Tropical Climate Rating (+40°C): Engineered with a heavy-duty cooling system rated for operation in ambient room temperatures up to +40°C and 40% relative humidity.
-
Ventilated Forced-Air Circulation: Powerful internal fan system distributes cold air evenly throughout the cabinet, maintaining strict food-safe temperatures (-2°C to +8°C) even during frequent door openings.
-
Heated Door Frames & Tool-Free Gaskets: Features concealed doorframe heating elements to eliminate condensation moisture, along with magnetic gaskets that unclip easily without tools for routine cleaning or replacement.
-
Low Energy Footprint & Eco-Friendly Insulation: Built with 60mm thick high-density HC-free polyurethane insulation to lock in cold temperatures and minimize compressor draw.
-
Automatic Defrost & Self-Evaporating Drainage: Automated defrost system paired with an internal condensate evaporation loop eliminates manual drip tray emptying.
-
Standard 10A Plug-and-Play Power Setup: Operates on single-phase 240V power (300W) and plugs directly into any standard Australian 10 Amp wall outlet.
-
Extended 2+2 Year Warranty Protection: Supported by 2 Years Parts & Labour plus an additional 2 Years Parts Only Warranty when registered online within 14 days of invoice date.
Technical Specifications
| Feature |
Specification Details |
| Brand & Model |
Thermaster GN3100TNC |
| Product Type |
Commercial Double-Sided Pass-Through Refrigerated Island Counter Workbench |
| Pass-Through Layout |
2 x 3 Solid Doors (3 Doors on Front + 3 Doors on Rear side of cabinet) |
| Capacity & Pan Sizing |
Gross Volume: 324L | Sized to fit GN 1/1 Gastronorm Pans |
| External Dimensions (WxDxH) |
1795 mm W x 700 mm D x 860 mm H |
| Temperature Set Range |
-2°C to +8°C |
| Max Ambient Climate Rating |
Rated for up to +40°C Ambient / 40% Relative Humidity |
| Cabinet Build Materials |
Complete AISI 304 Stainless Steel Interior & Exterior | Coved Corners |
| Insulation & Refrigerant |
60 mm HC-Free High-Density Thermal Insulation |
| Cooling & Control System |
Ventilated Air Circulation | Electronic Thermostat with Digital LED Display |
| Door Features |
Self-Closing Solid Doors | Heated Frame Elements | Tool-Free Replaceable Gaskets |
| Defrost & Drainage |
Automated Defrosting with Automatic Condensation Evaporation System |
| Power Supply |
240V / 50Hz / Single Phase (300W / Standard AU 10A Plug) |
| Warranty |
2 Years Parts & Labour + 2 Years Parts Only (Registration Required) |
Warranty Registration Notice: To activate the extended 2 Years Parts Only warranty (total 4 years parts coverage), products must be registered online within 14 days of invoice date.
Delivery & Freight Notice: Commercial heavy equipment requires dedicated tail-lift freight handling. Please contact our commercial sales team for a custom freight quote if delivery is required for a residential or non-commercial address.
Operating & Cleaning Guidelines
-
Placement & Setup: Position the island counter on a flat, level central floor space. Plug into a dedicated 240V 10A wall outlet and allow the cabinet to pull down to set target temperature (-2°C to +8°C) before loading GN 1/1 food pans.
-
Stock Loading & Workflow: Arrange pre-chilled ingredients inside GN 1/1 pans or on internal wire shelves, ensuring stock is accessible from both front and rear doors without blocking internal fan air vents.
-
Daily Hygiene & Maintenance: Wipe down the AISI 304 stainless steel benchtop and internal surfaces using a warm water solution and mild food-safe sanitiser. Unclip and clean magnetic door gaskets regularly to maintain a tight thermal seal.
Frequently Asked Questions
1. What is a pass-through refrigerated island counter?
A pass-through island counter features access doors on both the front and rear faces of the cabinet. Designed to sit in the middle of a commercial kitchen prep area, it allows staff working on opposite sides of the island to reach inside the same refrigerated cabinet without walking around the bench.
2. What size Gastronorm pans fit in the Thermaster GN3100TNC?
The GN3100TNC is specifically engineered to accommodate standard GN 1/1 Gastronorm pans and associated wire shelf grids across its 324-litre capacity.
3. What electrical supply is required for installation?
The unit draws 300W on single-phase 240V power and plugs directly into a standard Australian 10 Amp wall outlet.
4. Why are the door frames heated?
Concealed heating elements inside the doorframes prevent moisture condensation and sweating from forming on the stainless steel exterior during humid trading shifts, keeping workspace surfaces dry.
5. How do I activate the extended 4-year warranty protection?
The island counter includes a standard 2-year commercial parts and labour warranty. Registering the product online within 14 days of invoice date unlocks an additional 2 years of parts-only cover (providing 4 years total parts protection).
N.B Image is for illustrative purposes only. Specifications are subject to change without notice.
