The Tecnodom TDVB80-CA-187 Vulcano Commercial 3 Glass Door Display Fridge is an authentic Italian-made, high-capacity vertical merchandising display refrigerator engineered specifically for modern Australian supermarkets, delicatessens, butcher shops, fruit markets, and commercial grocery stores. Built with an expansive 3.79 m² display surface area, three 620mm wide hinged glass doors, and a durable stainless steel cabinet body, this premium display chiller provides maximum visual appeal and rapid cold-air circulation across high-turnover food stock.
Designed for simple installation and low ongoing maintenance, the TDVB80-CA-187 features a high-performance ventilated cooling system operating at a strict food-safe temperature range of 0°C to +4°C (Climate Class 4 rated up to +30°C / 55% RH). Powered by a built-in condensing unit with an automated stainless steel serpentine water evaporation system (CG), it includes bright top ceiling LED lighting, 380mm deep adjustable display shelves, heavy-duty castors for easy positioning, and dual power leads (1 x 15 Amp main circuit + 1 x 10 Amp dedicated tropical tundish circuit) backed by a 2-Year Parts and Labour Warranty.
Why Choose the Tecnodom TDVB80-CA-187 Vulcano 3 Glass Door Display Fridge?
Choosing the Tecnodom TDVB80-CA-187 Vulcano Display Fridge equips high-traffic food retailers with a sophisticated, highly reliable Italian-engineered refrigeration merchandising solution built for performance and durability.
Key reasons commercial operators specify the Tecnodom TDVB80-CA-187 include:
-
Authentic Italian Engineering & Build Quality: Manufactured in Italy with commercial-grade stainless steel construction and premium components for exceptional operational longevity.
-
Massive 3.79 m² Product Merchandising Area: Broad 1955mm wide cabinet profile equipped with three 620mm wide glass doors provides extensive display area for fresh meats, dairy, produce, and pre-packaged foods.
-
Food-Safe Ventilated Cooling System (0°C to +4°C): Dynamic forced-air refrigeration maintains uniform holding temperatures across all shelf levels to extend product shelf life.
-
Dual Power Circuit with Tropical Tundish: Features two independent power plugs—a 15 Amp main refrigeration supply (3100W) plus a separate 10 Amp circuit (1000W) powering a dedicated tropical tundish element for automated condensate evaporation.
-
Automatic Condensate Evaporation System: Fitted with an automated water evaporation system featuring a stainless steel serpentine coil to manage defrost runoff effectively.
-
Climate Class 4 Rating (+30°C / 55% RH): Commercial climate rating ensures consistent holding temperatures during Australian trading conditions.
-
Energy-Efficient Top Ceiling LED Lighting: High-output LED canopy lighting highlights product colors and bottle labels to capture customer attention and drive impulse sales.
-
380mm Deep Adjustable Display Shelving: Versatile multi-tier 380mm deep shelf layout allows custom product staging to suit various container heights.
-
Heavy-Duty Castors Included: Mounted on sturdy swivel castors for smooth positioning and hassle-free floor sanitation during maintenance.
-
2-Year Parts & Labour Warranty: Fully supported by a comprehensive 2-Year Commercial Parts and Labour Warranty for ultimate investment peace of mind.
Technical Specifications
| Feature |
Specification Details |
| Brand & Model |
Tecnodom TDVB80-CA-187 (Vulcano Series) |
| Origin |
100% Italian Made |
| Product Type |
Commercial Supermarket Three Glass Door Vertical Display Chiller |
| Display Surface Area |
3.79 m² Total Display Surface Area |
| Dimensions (WxDxH) |
1955 mm W x 765 mm D x 2130 mm H |
| Temperature Set Range |
0°C to +4°C |
| Climate Class Rating |
Climate Class 4 (Rated for +30°C Ambient / 55% Relative Humidity) |
| Door Configuration |
3 x 620 mm Wide Hinged Glass Doors |
| Cooling & Defrost System |
Ventilated Air Circulation | Auto Evaporation System with S/S Serpentine |
| Drainage Requirement |
Tundish drain required |
| Cabinet Construction |
Commercial Stainless Steel Body | Integrated Built-In Condensing Unit |
| Lighting System |
High-Output Top Ceiling LED Interior Lighting |
| Shelving System |
Multi-Tier Adjustable Display Shelves (380 mm Shelf Depth) |
| Mobility Assembly |
Heavy-Duty Swivel Castors Included |
| Net Weight |
280.0 kg |
| Power Supply |
3100W + 1000W (Requires 1 x 15 AMP Plug + 1 x 10 AMP Plug) |
| Warranty |
2 Years Parts and Labour Warranty |
Electrical Installation Note: This commercial unit requires two separate power circuits: one dedicated 15 Amp plug (3100W for main refrigeration) and one dedicated 10 Amp plug (1000W for the tropical tundish evaporation heater).
Plumbing & Delivery Notice: A tundish drain connection is required for operation. Commercial heavy equipment requires dedicated tail-lift freight handling. Please contact our commercial sales team for a custom freight quote if delivery is required for a residential or non-commercial address.
Operating & Maintenance Guidelines
-
Electrical & Plumbing Installation: Ensure appropriate dual electrical outlets are available (1 x 15A wall socket and 1 x 10A wall socket). Connect the unit to a suitable tundish drain in accordance with local plumbing codes before connecting power.
-
Initial Pull-Down & Loading: Allow the ventilated cooling system to operate empty until reaching target temperature (0°C to +4°C) before loading merchandise. Arrange stock evenly across the 380mm deep shelves without blocking internal air circulation channels.
-
Routine Cleaning & Hygiene: Regularly wipe down the stainless steel exterior and internal walls with a warm water solution and mild food-safe sanitiser. Inspect glass door gaskets and ensure the condenser coil is cleaned periodically as outlined in the user manual.
Frequently Asked Questions
1. Why does the Tecnodom TDVB80-CA-187 require two power plugs?
The unit utilizes two separate electrical circuits to manage heavy commercial loads safely: a 15 Amp plug (3100W) powers the main refrigeration compressor and fan system, while an extra 10 Amp plug (1000W) operates a separate heating element for the tropical tundish automatic condensate evaporation system.
2. Where is this supermarket display fridge manufactured?
The Tecnodom TDVB80-CA-187 Vulcano fridge is designed and manufactured in Italy, offering premium construction, sleek aesthetics, and high-efficiency commercial performance.
3. Does this unit require a drainage line?
Yes, a tundish drain connection is required during installation to manage condensation water effectively alongside the automatic stainless steel serpentine evaporation system.
4. What are the shelf dimensions for product display?
The unit features multi-tier display shelving with a generous shelf depth of 380mm, offering an overall total display surface area of 3.79 m².
5. What warranty is included with the Tecnodom TDVB80-CA-187?
This display fridge comes standard with a full 2-Year Parts and Labour Warranty, covering repair costs and component replacements during the warranty period.
N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
