The TDVB80-CA-125 Vulcano 2-Door Commercial Supermarket Glass Display Refrigerator is a high-capacity, heavy-duty vertical merchandising fridge engineered specifically for Australian supermarkets, convenience stores, petrol stations, delis, and high-volume grocery outlets. Featuring a generous 2.54m² display surface, 620mm wide glass hinged doors, and an internal stainless steel body structure, this vertical display fridge maximizes product visibility while keeping chilled dairy, meats, drinks, and packaged foods at optimal serving temperatures (0°C to +4°C).
Designed for effortless installation and low long-term maintenance, the Vulcano TDVB80-CA-125 features a built-in condensing unit and a high-efficiency ventilated cooling system for uniform temperature distribution across all shelf tiers. To handle high-humidity commercial environments, the cabinet is fitted with an automatic water evaporation system with a stainless steel serpentine coil, paired with a dedicated 1000W tropical tundish heating circuit. Operating on two standard 10 Amp power connections, this mobile display unit sits on heavy-duty castors and is supported by a 2-Year Parts & Labour Warranty.
Why Choose the Vulcano TDVB80-CA-125 Vulcano Supermarket Display Fridge?
Choosing the TDVB80-CA-125 Vulcano 2-Door Display Refrigerator equips commercial retail venues with a robust, high-visibility merchandising station designed for maximum product throughput.
Key reasons commercial operators specify the Vulcano TDVB80-CA-125 include:
-
Expansive 2.54m² Display Surface: Designed with two wide 620mm hinged glass doors and deep 380mm adjustable shelves to maximize retail stock presentation and drive front-of-house customer sales.
-
Rapid Ventilated Airflow Cooling (0°C to +4°C): Powerful fan-forced air circulation delivers fast cold air recovery during peak trade, maintaining steady internal temperatures ideal for pre-packaged meats, dairy, and beverages.
-
Tropical Tundish & Automatic Evaporation System: Features a built-in stainless steel serpentine hot gas loop for automatic water evaporation, backed by a separate dedicated 1000W tropical tundish element to prevent overflow in humid Australian climates.
-
Plug-and-Play Dual Circuit Setup (2 x 10A Plugs): Simple installation via two separate single-phase 10 Amp power cords (1830W primary cooling circuit + 1000W separate tundish heating circuit), eliminating the need for complex three-phase hardwiring.
-
Top Ceiling LED Lighting: High-output ceiling-mounted LED lighting brightly illuminates every shelf level, showcasing product packaging without introducing unnecessary heat into the cabinet.
-
Heavy-Duty Castors for Easy Position Shifts: Fitted with sturdy castor wheels for smooth maneuvering during aisle layout changes and effortless cleaning underneath.
-
Commercial Stainless Steel Body: Heavy-duty internal stainless steel construction resists corrosion, scratches, and daily impacts from high-volume supermarket traffic.
-
2-Year Full Commercial Warranty: Fully supported nationwide with a 2-Year Parts and Labour Warranty for total peace of mind.
Technical Specifications
| Feature |
Specification |
| Model / Series |
TDVB80-CA-125 (Vulcano Supermarket Range) |
| Product Type |
Vertical Commercial 2-Door Glass Merchandising Display Refrigerator |
| Total Display Area |
2.54 m² Display Surface |
| Door Configuration |
2 x 620 mm Wide Hinged Glass Display Doors |
| Temperature Set Range |
0°C to +4°C |
| Cooling Mechanism |
Ventilated Airflow / Fan-Forced Refrigeration |
| Condensing Unit |
Built-in Internal Condensing Unit |
| Evaporation & Drainage |
Automatic Water Evaporation with Stainless Steel Serpentine Coil + Tundish Drain |
| Climate Class Rating |
Class 4 (Rated for +30°C Ambient / 55% Relative Humidity) |
| Shelf Depth |
380 mm Deep Adjustable Shelves |
| Cabinet Construction |
Stainless Steel Internal Body with Overhead LED Lighting |
| Mobility Assembly |
Heavy-Duty Castor Wheels Included |
| External Dimensions (WxDxH) |
1330 mm W x 765 mm D x 2130 mm H |
| Electrical Power Draw |
1830W Main Circuit + 1000W Tundish Circuit (Requires 2 x Standard AU 10A Outlets) |
| Warranty |
2 Years Parts and Labour Warranty |
Plumbing & Drainage Notice: This unit requires connection to a standard tundish drain line for manageability during high-humidity defrost cycles.
Delivery & Freight Notice: Commercial heavy equipment requires dedicated tail-lift freight handling. Please contact our commercial sales team for a custom freight quote if delivery is required for a residential or non-commercial address.
Operating & Cleaning Guidelines
-
Setup & Dual Electrical Connection: Roll the cabinet into position on a level floor and lock castors. Connect the unit's two power plugs into two separate standard single-phase 240V 10A wall outlets (one for the main cooling circuit, one for the 1000W tropical tundish circuit). Connect the overflow outlet to a tundish drain line before powering on.
-
Pre-Chilling & Stock Loading: Allow the cabinet to run empty until it reaches its target set temperature (0°C to +4°C). Load pre-chilled retail products evenly across the 380mm deep shelves, taking care not to block internal rear air vents to maintain uniform ventilated circulation.
-
End-of-Shift Sanitisation: Periodically wipe down the internal stainless steel liner, shelf rails, and glass doors using a soft cloth with warm water and a mild food-safe sanitiser. Clear the bottom drain pan area regularly to prevent debris from clogging the tundish drain path.
Frequently Asked Questions
1. Why does the Vulcano TDVB80-CA-125 require two power plugs?
The unit utilizes two separate electrical circuits on standard 10 Amp plugs: one 1830W circuit powers the main compressor, ventilated fans, and LED lighting, while a separate 1000W circuit powers the auxiliary tropical tundish heater element to manage condensate in humid environments.
2. Does this display fridge require a tundish floor drain connection?
Yes, a tundish drain connection is required to handle excess condensation runoff during heavy defrost cycles or extreme ambient humidity conditions.
3. What is the shelf depth and display capacity of the TDVB80-CA-125?
The unit features 380mm deep adjustable shelving tiers offering a total merchandising display surface area of 2.54m².
4. What is the ambient temperature rating for this model?
The Vulcano TDVB80-CA-125 is rated to Climate Class 4 standards, operating effectively in ambient environments up to +30°C with 55% relative humidity.
5. What warranty coverage is included with the Vulcano display fridge?
This unit includes a 2-year (24-month) commercial parts and labour warranty.
N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
