Easy to use, Smeg hood type dishwashers offer an absolute guarantee of hygiene for all types of crockery including plates, fine glassware and cutlery.
Thanks to the clever design, the traditional outer handles have been replaced by an innovative front handle, while the hood lifting elements are positioned inside the back panel to optimise the effective volume of the internal tank without altering the overall dimensions.
Perfect for cafes, bars, restaurants, wine bars, bakeries, delicatessens and schools.
Type: Hoodtype dishwasher
Basket dimensions: 500 x 500 mm
Control Panel: Electronic
Standard drain pump with partial water renewal in the wash tank: Yes
Rinse Pump: HTR System
Boiler Type: Atmosferic boiler
Wash Pump: Standard
Usable load height: 470mm
Maximum height with open hood: 2138 mm
Product dimensions: 634 mm W x750 D x 1523 H
LED colour: Green
Functions: GN 1/1 trays washing; 5-stage filter; HTR; Door clearance 470mm
Technical Features:
Trays number: 7 x GN1/1
Trays Washing Option: Yes
Programs:
Programs: 3 automatic programs - 90-150-240 seconds
Program options: Extra rinse; Clean water cycle
Drain and self cleaning cycle: Yes
Maximum basket/ hour: 40
Maximum dishes/ hour: 720
Maximum glasses/ hour: 1440
Interface:
Display: 4 digit
Number of buttons: 5
On/Off button: Yes
Cycle progress alert: Yes
End-cycle alert: Yes
Manual diagnostic: Yes
Construction:
Tank: Deep drawn
Construction: Single-skin hood
Tank material: Stainless steel AISI 304
Back panel: Prepainted
Upper washing system: One washing and one split rinse spray arms, stainless steel
Lower washing system: One washing and one split rinse spray arms, stainless steel
Tank filter: Stainless steel
Hood elevation system: Manual
Filter: 5-stages filter system
Hood: Single wall
Tank capacity: 14 L
Boiler capacity: 10 L
Adjustable feet: Yes
Net weight: 107 Kg
Drain max height: 1000 mm
Technical Features:
Tank heating element: 1400 W
Boiler heating element: 2600 W
Washing pump: 700 W
Default connection: 3400 W
Water cycle consumption: 3.2 L
Wash temperature (min-max): 58°C
Rinse temperature (min-max): 87°C
Water inlet: 8°C
Max temperature inlet water: 60°C
Max water hardness: 5°f - 3°dH
Water inlet pressure: 100-1000kPa
Detergent load: 1.5 l/h
Rinse load: 0.4 l/h
Usable load height: 470 mm
Maximum height with open hood: 2138 mm
Electrical Connection:
Plug supplied: Australian 15 Amp
Electrical connection option: 230 V~ / 15 A / 3,3 kW / 50 Hz (NC)
Equipment:
Drain pump: Yes
Peristaltic detergent doser: Yes, electronic control
Peristaltic rinse-aid doser: Yes, electronic control
Default chemicals: gr/lt
Boiler thermostop: Yes default ON
Soft Start: Yes
Stand-by System: Yes
Automatic start: Yes default OFF
Detergent load: Yes, manual
Rinse load: Yes, manual
Filter: 5-stages filter system
Rinse pump H.T.R. system: Rinse pump with athmospheric boiler
Cycle counter: Yes
Break tank: Yes
Partial renewal of water in the tank and built-in drain pump: Yes
Trays washing option: GN 1/1 530x32 5mm
Water supply pipe diameter: 16mm
Drain supply pipe diameter: 21.5 mm
Peristaltic detergent doser: Yes, manual
Accessories included: Dish basket, cutlery basket, flat basket
Warranty: 24 Months Parts and Labour
Net Weight: 109.00 Kg
Gross Weight: 128 Kg
Please note this model is replacing the SPH505AU15.
**As this is 15amp dishwasher it needs to be connected to hot water for recovery.**
N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
