Hobart ECOMAX F504 Commercial Under-Bench Dishwasher (Made in Germany)

The Hobart ECOMAX F504 Commercial Under-Bench Dishwasher is a high-capacity, German-engineered warewashing solution designed specifically for busy Australian clubs, bistros, taverns, cafes, fast-food outlets, and commercial kitchens. Sized at 576 mm Wide x 604 mm Deep x 820 mm High, this compact floor-standing under-counter dishwasher integrates seamlessly beneath standard workbenches while processing up to 60 racks per hour using standard 500 mm x 500 mm dish racks.

Featuring intuitive single-button electronic controls with a digital temperature display, the ECOMAX F504 provides thorough, hygienic cleaning across 3 selectable wash cycles (60, 120, and 180 seconds) alongside a specialized high-temperature hygiene program. Operating on a versatile electrical setup (240V / 15 Amp single-phase standard plug connection, convertible to 400V 3-phase for rapid multi-cycle recovery), it consumes a minimal 2.0 litres of fresh rinse water per rack across a 25-litre wash tank. Outfitted with rotating top and bottom wash arms, indented anti-clog nozzles, tool-free removable rinse arms, double-walled insulated housing, an integrated rinse pressure pump, and a tank strainer, it comes backed standard by a 12-Month Hobart Manufacturer Warranty.

Why Choose the Hobart ECOMAX F504 Under-Bench Dishwasher?

Selecting the Hobart ECOMAX F504 Commercial Dishwasher equips kitchen managers, head chefs, and venue operators with a robust, German-made warewashing engine designed for pristine plates, fast turnarounds, low operating costs, and long-term service reliability.

Key benefits of the Hobart ECOMAX F504 include:

• German Precision & Build Quality: Engineered and built in Germany to strict commercial standards, delivering superior thermal efficiency, structural durability, and quiet operation.

• High Output Productivity (Up to 60 Racks/Hour): Rapid wash cycle settings (60, 120, and 180 seconds) keep pace with heavy kitchen pass-through demands during peak dining rushes.

• Ultra-Low Water Consumption (2.0L per Rack): Consumes just 2.0 litres of fresh rinse water per rack cycle, keeping venue power, water, and chemical costs to an absolute minimum.

• Integrated Rinse Pressure Pump: Built-in rinse pressure pump guarantees consistent, optimal water flow pressure regardless of fluctuating site water mains pressure.

• Single-Button Control & Thermostop Hygiene: Simple, flat-surface single-button interface with real-time digital temperature readouts and Thermostop lock function ensures guaranteed sanitizing rinse temperatures every cycle.

• Tool-Free Removable Wash Arms & Non-Clog Nozzles: Rotating stainless steel upper and lower wash arms distribute water evenly while indented nozzles prevent blocking from food scraps. Wash arms unclip instantly without tools for easy cleaning.

• Quiet Double-Walled Housing & Front Door: Insulated double-walled casing retains heat inside the 25L wash chamber while maintaining low ambient noise levels in open kitchen or bar areas.

• Complete Standard Accessories: Supplied standard with a 500x500 mm P-18-12 plate rack, CB1 cutlery basket, built-in rinse aid dispenser, power lead, water supply hose, and flexible drain hose.

• 12-Month Hobart Warranty: Backed standard by a 12-Month Hobart Commercial Manufacturer Warranty.

Technical Specifications

Site Installation & Water Supply Requirements

To guarantee machine longevity, optimal wash hygiene, and validate manufacturer warranty coverage, observe the following setup parameters:

1. Trade Installation: Installation must be conducted by a licensed plumber and electrician observing all local Australian plumbing (AS/NZS 3500) and electrical (AS/NZS 3000) regulations.

2. Water Supply Pressure: Required incoming line water pressure is 0.8 to 6.0 bar (facilitated by the integrated rinse pressure pump).

3. Water Hardness Protection: For complete internal component protection against limescale build-up, incoming water hardness must not exceed 3°dH. If site water hardness exceeds 3°dH, installation of a Hobart HYDROLINE water softener or treatment system is strongly recommended.

4. Back-Flow Safety: Machines fitted with an integrated water softener require an approved back-flow safety device fitted at the site connection point in accordance with DVGW-DIN 1988 standards.

Operating & Cleaning Guidelines

1. Setup & Pre-Heating: Turn on incoming water supply and main power. Press the single-button electronic controller. The unit fills and pre-heats the 25L wash tank automatically, displaying real-time digital wash temperatures.

2. Loading & Washing: Scrap off heavy food scraps from plates into a waste bin before loading items into the 500x500 mm P-18-12 plate rack. Slide the rack into the 360 mm opening, select your wash cycle (60s, 120s, or 180s), close the double-walled door, and press start.

3. Daily Maintenance & Cleaning: At the end of trade, run the automated drain/hygiene cycle. Switch off power, remove and rinse the main tank strainer under running water. Unclip the upper and lower wash arms without tools, clear any trapped debris from the indented nozzles, wipe down the wash chamber, and leave the front door slightly ajar overnight to dry.

Frequently Asked Questions

1. Where is the Hobart ECOMAX F504 manufactured?

The Hobart ECOMAX F504 is designed and manufactured in Germany, guaranteeing exceptional build quality, thermal performance, and long-term durability.

2. What rack size does the Hobart ECOMAX F504 accept?

This commercial under-bench dishwasher uses industry-standard 500 mm x 500 mm dish and glass racks, featuring a generous 360 mm clear internal door loading height for large dinner plates and tall glassware.

3. What electrical connection is required for this machine?

Standard supply is 240V / 50Hz single-phase electricity pre-fitted with a 15 Amp plug and lead (2.2 kW). For high-turnover venues requiring fast continuous wash recovery, it can also be configured for 400V 3-phase power (5.9 kW load).

4. Why is a water treatment system recommended for the F504?

To protect internal heating elements, wash pumps, and water nozzles from severe limescale accumulation, Hobart specifies that incoming water hardness should not exceed 3°dH. Installing a Hobart HYDROLINE water softener ensures optimal wash results and protects your machine investment.

5. What warranty covers the Hobart ECOMAX F504 dishwasher?

The Hobart ECOMAX F504 comes backed standard by a 12-Month Hobart Commercial Manufacturer Warranty.

N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
