GasMax RC400ELPG Superfast LPG Commercial Single Vat Tube Fryer (394mm Wide)

[GASMAX_MSG]

The GasMax RC400ELPG Superfast LPG Commercial Single Vat Tube Fryer is a high-output, fast-recovery deep frying station engineered specifically for Australian fish and chip shops, takeaways, food trucks, pubs, clubs, and high-volume commercial kitchens operating on bottled gas. Sized at 394 mm Wide x 759 mm Deep x 1,195 mm High, this compact floor-standing unit delivers an exceptional production output of up to 35 kg of crispy fried food per hour, making short work of peak meal rushes.

Built for heavy daily commercial use, the RC400ELPG features a 22-litre recommended oil capacity (26-litre total tank capacity) housed inside a heavy-duty stainless steel vat with a built-in flue deflector and removable lid. Powered by an intense 110 MJ/h multi-jet tube burner system with a premium Robshaw millivolt mechanical valve and flame failure protection (120°C to 200°C), it delivers ultra-fast thermal recovery times. Complete with a deep cold zone below the heating tubes, a 32 mm full-port drain valve, two wire baskets, adjustable legs, and IAPMO certification (#GMK10174), it is backed by an outstanding 2-Year Parts & Labour + 2-Year Parts Only Warranty (upon product registration within 14 days of invoice).

Why Choose the GasMax RC400ELPG LPG Single Vat Fryer?

Selecting the GasMax RC400ELPG Commercial LPG Tube Fryer equips venue managers and head chefs with a high-capacity, fast-recovering deep frying station designed to maximize kitchen throughput while keeping oil consumption low.

Key advantages of the GasMax RC400ELPG include:

• High-Output Frying Capacity (35 kg/hr Output): Delivers up to 35 kg of crispy chips, fish, or chicken per hour, ensuring your kitchen stays ahead during intense lunch and dinner trade.

• Intense 110 MJ/h Multi-Jet LPG Tube Burners: Powerful gas heating design transfers heat directly through the oil, achieving rapid thermal recovery when lowering large, frozen batches.

• Deep Cold Zone Sediment Protection: Food particles fall below the burner tubes into a cooler oil zone, preventing burnt debris, bitter oil flavours, and extending overall oil usability.

• Reliable Robshaw Millivolt Control (120°C to 200°C): Industry-standard Robshaw valve and mechanical thermostat manage temperatures precisely without requiring a 240V mains electrical connection.

• Heavy-Duty 32mm Ball-Type Full-Port Drain Valve: Large 32 mm drain valve allows fast, clog-free oil drainage and easy vat filtering during end-of-shift maintenance.

• Full Stainless Steel Construction & Accessories: Heavy-duty stainless steel front, door, tank, and trim. Supplied complete with a removable stainless steel lid, 2 wire baskets, and a lift-off basket hanger.

• Certified Gas Safety Compliance: Built with flame failure safety protection and certified under IAPMO Approval #GMK10174 to satisfy all Australian commercial gas safety standards.

• Easy Front Service Access & Adjustable Legs: All key gas components are easily accessible from the front panel, supported by heavy-duty height-adjustable stainless steel legs.

• Up to 4-Year Commercial Warranty: Backed standard by a 2-Year Parts & Labour Warranty, extendable by an additional 2 Years Parts Only upon online product registration within 14 days of invoice.

Technical Specifications

Gas Installation & Commissioning Notice: Under Australian law, all commercial gas equipment must be installed and commissioned by a qualified, licensed gas plumber after installation. Proof of licensed gas commissioning is required to validate manufacturer warranty coverage.

Delivery & Freight Notice: Commercial heavy cooking equipment requires dedicated freight handling. Please contact our friendly sales team for a custom freight quote if delivery is required for a residential or non-commercial address.

Operating & Cleaning Guidelines

1. Setup & Commissioning: Ensure a licensed gas fitter connects the 1/2" LPG gas line, verifies gas pressure, and completes official commissioning. Fill the stainless steel vat with commercial frying oil up to the 22L line before igniting the burners.

2. Ignition & Frying: Light the standby pilot using the Robshaw millivolt control knob. Turn the thermostat dial to your target frying temperature (120°C–200°C). Once pre-heated, lower filled wire baskets into the oil to achieve fast, crisp frying.

3. Daily Hygiene & Oil Maintenance: At the end of service, turn off the gas supply and allow oil to cool. Open the 32 mm ball-type drain valve to filter oil through a heat-safe strainer. Wipe down the stainless steel tank interior, cold zone, and exterior panels with warm, soapy water and a mild commercial degreaser.

Frequently Asked Questions

1. Does the GasMax RC400ELPG require a 240V electrical connection?

No. The GasMax RC400ELPG operates using a self-generating Robshaw millivolt control system with a standing pilot light, meaning it functions entirely on gas power without needing an electrical wall plug.

2. What is the hourly production output of the GasMax RC400ELPG?

The GasMax RC400ELPG is capable of producing up to 35 kg of crispy fried chips or food per hour, making it ideal for busy takeaway lines and food trucks.

3. How does the cold zone extend oil life?

The tube heating design leaves a section of oil below the burner tubes at a lower temperature. Crumbs and food particles sink into this "cold zone" rather than staying against hot heating surfaces, preventing scorching and keeping cooking oil cleaner for longer.

4. Are the frying baskets and lid included with the unit?

Yes. The GasMax RC400ELPG comes complete with two heavy-duty commercial wire baskets and a stainless steel vat cover lid as standard equipment.

5. What warranty covers the GasMax RC400ELPG gas fryer?

This commercial gas fryer comes standard with a 2-year parts and labour warranty, which extends by an additional 2 years for parts only when registered online within 14 days of invoice.

N.B Images are for illustrative purposes only.  Specifications are subject to change without notice.
