Low Temperature, Low Costs
Low temperature cooking (LTS) is a gain in quality and guaranteed savings. Low Temperature Cooking allows you to obtain more than 50% of weight loss compared to traditional cooking. Magistar Combi works even if you are absent and, when you return, you will find everything ready. This cooking cycle is ideal for all types of meat and oven-baked fish.
Many Cooking Options, Great Savings:
If you have a complex menu that requires different types of simultaneous cooking, Magistar Combi will help you out. The Multitimer allows you to set up to 20 different times simultaneously! Each time one of the foods reaches the set cooking temperature, Magistar Combi sounds an alarm to remove it from the oven.
Main Features:
• 2 different chemical options available: solid and liquid (requires optional accessory).
• Capacity: 10 GN 2/1 or 20 GN 1/1 trays.
• Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory – contact the Company for more details).
• High resolution full touch screen interface (translated in more than 30 languages) - colour-blind friendly panel.
• Built-in steam generator for highly precise humidity and temperature control according to the chosen settings.
• Real humidity control based upon Lambda Sensor to automatically recognize quantity and size of food for consistent quality results.
• Dry, hot convection cycle (25°C - 300°C): ideal for low humidity cooking.
• Combination cycle (25°C - 300°C): combining convected heat and steam to obtain humidity controlled cooking environment, accelerating the cooking process and reducing weight loss.
• Low temperature Steam cycle (25°C - 99°C): ideal for sous-vide, re-thermalization and delicate cooking. Steam cycle (100 °C): seafood and vegetables. High temperature steam (25°C - 130°C).
• Automatic mode including 9 food families (meat, poultry, fish, vegetables, pasta/rice, eggs, savoury and sweet bakery, bread, dessert) with 100+ different preinstalled variants. Through Automatic Sensing Phase the oven optimizes the cooking process according to size, quantity and type of food loaded to achieve the selected cooking result. Real time overview of the cooking parameters. Possibility to personalize and save up to 70 variants per family.
• Special Cycles:
Regeneration (ideal for banqueting on plate or rethermalizing on tray)
Low Temperature Cooking (to minimize weight loss and maximize food quality)
Proving cycle
EcoDelta cooking, cooking with food probe maintaining pre-set temperature difference between the core of the food and the cooking chamber
Sous-vide cooking
Static Combi (to reproduce traditional cooking from static oven)
Pasteurization of pasta
Dehydration cycles (ideal for drying fruits, vegetables, meats, seafood)
Food Safe Control (to automatically monitor safety of cooking process in compliance with HACCP hygienic standards)
Advanced Food Safe Control (to drive the cooking with pasteurization factor)
• Programs mode: a maximum of 1000 recipes can be stored in the oven's memory, to recreate the exact same recipe at any time. The recipes can be group in 16 different categories to better organize the menu. 16-step cooking programs also available.
• MultiTimer function to manage up to 20 different cooking cycles at the same time, improving flexibility and ensuring excellent cooking results. Can be saved up to 200 MultiTimer programs.
• AirFlow air distribution system to achieve maximum performance in chilling/heating evenness and temperature control thanks to a special design of the chamber combined with high precision variable speed fan.
• Fan with 7 speed levels from 300 to 1500 RPM and reverse rotation for optimal evenness. Fan stops in less than 5 seconds when door is opened.
• 6-point multi sensor core temperature probe for maximum precision and food safety.
• Pictures upload for full customization of cooking cycles.
• Automatic fast cool down and pre-heat function.
• Make-it-mine feature to allow full personalization or locking of the user interface.
• SoloMio lets the user group the favourite functions in the homepage for immediate access.
• Calendar works as an agenda where the user can plan the daily work and receive personalized alerts for each task.
• Grease Collector: predisposed for integrated grease drain and collection for safer operation (dedicated base as optional accessory).
• USB port to download HACCP data, share cooking programs and configurations. USB port also allows to plugin sous-vide probe (optional accessory).
• Connectivity ready for real time access to connected appliances from remote and HACCP monitoring (requires optional accessory).
• Training and guidance supporting materials easily accessible by scanning QR-Code with any mobile device.
• Back-up mode with self-diagnosis is automatically activated if a failure occurs to avoid downtime.
• Automatic consumption visualization at the end of the cycle.
Construction:
• Double thermo-glazed door with open frame construction, for cool outside door panel. Swing hinged easy-release inner glass on door for easy cleaning.
• Seamless hygienic internal chamber with all rounded corners for easy cleaning.
• 304 AISI stainless steel construction throughout.
• Front access to control board for easy service.
• Integrated spray gun with automatic retracting system for fast rinsing.
• IPX 5 spray water protection certification for easy cleaning.
• Supplied with n.1 tray rack 2/1 GN, 67 mm pitch.
Sustainability:
• Reduced power function for customized slow cooking cycles.
• HP Automatic Cleaning: Automatic and built-in self cleaning system with integrated descale of the steam generator. 5 automatic cycles (soft, medium, strong, extra strong, rinse only) and green functions to save energy, water, detergent and rinse aid. Also programmable with delayed start.
• Cooking Optimizer function organizes the cooking sequence of the chosen cycles optimizing the work in the kitchen from a time and energy efficiency point of view.
Specifications:
Electric:
Supply Voltage: 400-430 V/3N ph/50-60 Hz
Electrical power, default: 37.4 kW
Electrical power max: 39 kW
Circuit breaker required.
Water:
Water inlet "FCW" connection: 3/4"
Pressure, bar min/max: 1-6 bar
Drain "D": 50mm
Max inlet water supply temperature: 30°C
Chlorides: <17 ppm
Conductivity: >50 µS/cm
Installation:
Clearance: 5cm rear and right hand sides
Suggested clearance for service access: 50 cm left hand side
Capacity:
GN: 10 - 2/1 Gastronorm
Max load capacity: 100 kg
Key Information:
External Dimensions: Width: 1090 mm, Depth: 971 mm, Height: 1058 mm
Weight: 189.5 kg
Net Weight: 189.5 kg
Shipping Weight: 214.5 kg
Shipping Volume: 1.58 m³
Warranty: 24 Months Parts & Labour
Country of Origin: Italy
N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
