Guaranteed cooking uniformity - An accurately designed cooking chamber, featuring a specially engineered deflector, optimises the thermodynamics of the airflow, ensuring a uniform heat distribution. Thanks to this even distribution, cooking is quick and balanced, delivering consistent and precise results with every cycle.
Build quality - Refined design, advanced technology and high-quality materials come together to ensure excellent performance. The robust stainless steel structure guarantees strength and durability, while the double or triple-glazed door optimises heat retention and reduces energy consumption. Additionally, the design of the tray holders allows for the insertion of trays of various sizes, perfectly adapting to the needs of gastronomy, pastry and bakery.
Cooking parameters - With ALFA ovens, it is possible to customise every stage of the cooking process to achieve flawless results, catering to the specific needs of each dish. Thanks to the precise control of various parameters such as cooking steps, time, temperature, humidity level, and fan speed, every item reaches the ideal level of cooking, ensuring high-performance and superior quality at every stage of the process.
Energy saving - Smeg technologies are designed to minimise energy consumption and optimise efficiency. Among them, the use of double glazing and, in some models, triple glazing, which limit thermal fluctuations and reduce energy waste. Additionally, the ability to customise cooking parameters allows for more efficient resource management and waste reduction, ensuring perfect, even, and uniform cooking results
General Data:
Convection Oven 10 Trays EN 600x400mm or GN1/1
Oven Type: Fan with humidification
Oven Control: Electronic
Trays Capacity: 10 Trays GN1/1, 10 EN 600x400 mm (min. H20mm)
Product Dimensions: 798 mm W x 772 D x 1100 H
Power Supply: 400 V 3N~ / 23A / 16 kW / 50-60 Hz
Humidity Generation: Direct in Cavity
Adjustable Feet
Maximum Depth with Open Door: 1536 mm
Aesthetics:
Door with Stainless Steel Stripes
Colour: Stainless Steel
Display Type: LCD Touch
Digit Display Colour: White
Series: Alfa
Front Panel: Yes
Program/ Functions: Fan forced, Fan forced with humidification, Core temperature probe baking, Core probe + Δ t
Adjustable Fan Speed: Adjustable
Technical Features: Circular Heating Element - Power: 5000 W
Programs/ Functions: Haccp data
Controls:
Recipes Number: 100
Timer Setting Range: from 1 minute to 99 hours + endless
Cooking Steps: 3 + pre-heating
Delayed Start: Yes
Pre-heating: Yes
Chimney Regulation: Yes
Construction:
Oven Materials: Ever Clean Enamel
Cavity Dimensions: 672 mm L x 437 D x 854 H
Internal Net Volume: 616mm x 431 x 340
Cavity Material: Stainless Steel
Shelves Number: 10
Tray Frame Support: Chrome
Shelves Distance: 77 mm
Door Construction: Double glass
Door Opening: Lateral
Handle Type: New ergonomics
Openable Glass
Fan Type and Number: 3 Contrarotating fans with time direction reversal
Engine Speed: 200W
Water Injection on Each Fan: Yes
Humidification Levels: 3 + Manual
Exhaust Position: Back
Components Cooling System: Yes
Timer Type: Electronic Timer
Temperature Range: 30-270°C
End Cooking Signal: Yes
Manual Reset Safety Thermostat: Yes
Predisposition for Core Probe Δ t: Yes
Removable Deflector: Yes
Light Switch with Open Door: Yes
Lighting: 3 Halogen Lamps
Light Power: 40 W
USB Port: Yes
Water Load Pipe: Yes
Water Inlet Pressure: 50-500 kPa (min-max)
Power Cable Length: 170 cm
Back Panel: Galvanized
IPX Protection: IPX3
Net Weight: 105.800 Kg
Gross Weight: 122.000 Kg
Warranty: 24 Months Parts & Labour
N.B Images are for illustrative purposes only. Specifications are subject to change without notice.
